- Supports ISO 7816 Class A, B and C (5 V, 3 V, 1.8 V) card
- Supports CAC (Common Access Card)
- Supports PIV (Personal Identity Verification) Card
- Supports microprocessor cards with T=0 or T=1 protocol
- Supports memory cards:
- Cards following the I2C bus protocol (free memory cards), including:
- Atmel: AT24C01 / 02 / 04 / 08 / 16 / 32 / 64 / 128 / 256 / 512 / 1024
- SGS-Thomson: ST14C02C, ST14C04C
- Gemplus: GFM1K, GFM2K, GFM4K, GFM8K
- Cards with intelligent 256 bytes EEPROM and write protect function, including: SLE4432, SLE4442, SLE5532, SLE5542
- Cards with intelligent 1K bytes EEPROM and write-protect function, including: SLE4418, SLE4428, SLE5518, SLE5528
- Cards with '104' type of EEPROM non-reloadable token counter cards, including: SLE4406, SLE4436, SLE5536, SLE6636
- Cards with secure memory IC with password and authentication, including: AT88SC153, AT88SC1608
- Cards with Intelligent 416-Bit EEPROM with internal PIN check, including: SLE4404
- Cards with Security Logic with Application Zone, including: AT88SC101, AT88SC102, AT88SC1003
- Supports PPS (Protocol and Parameters Selection)
- Features Short Circuit Protection
- Application Programming Interface:
- Supports PC/SC
- Supports CT-API (through wrapper on top of PC/SC)
Dimensions
72.2mm (L) x 69.0mm (W) x 14.5mm (H)
Interface
USB 2.0 Full Speed
Supply Voltage
Regulated 5V DC
Supply Current
Max. 50mA
Operating Temperature
0-60°C
CLK Frequency
4 MHz
Smart Card Interface Support
- ISO-7816 Class A, B and C ( 5V, 3V, 1.8V )
- CAC Smart Cards
Compliance / Certifications
- EN60950/IEC 60950, ISO 7816, USB Full Speed, EMV™ Level 1 (Contact), PC/SC, CCID, CE, FCC, WEEE, UL, RoHS 2, REACH, FIPS 201 (USA), TAA (USA), J-LIS (Japan), VCCI (Japan), KC (Korea)
- Microsoft® WHQL
Operating System Support
- Windows®
- Linux®
- Mac OS®
- Android™
- Solaris
